| Brand Name: | SUMA of one-way sprag clutch |
| Model Number: | FGK của ly hợp sprag một chiều |
| MOQ: | 1 |
The FGK Series sprag freewheels feature bearing support in the dimensions of needle bearing series 59.
| Size | Nominal Torque (Nm) | Max Speed (min-1) | Load Rating (Dynamic) | Bore (mm) | D (mm) | K (mm) | L (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| FGK20 | 50 | 5,500 | 5,600 | 20 | 37 | 42 | 23 | 0.09 |
| FGK25 | 70 | 5,300 | 6,300 | 25 | 42 | 48 | 23 | 0.11 |
| FGK30 | 95 | 5,000 | 7,700 | 30 | 47 | 54 | 23 | 0.13 |
| FGK35 | 200 | 4,600 | 8,200 | 35 | 55 | 63 | 27 | 0.20 |
| FGK40 | 310 | 4,200 | 8,650 | 40 | 62 | 70 | 30 | 0.30 |
| FGK45 | 370 | 3,800 | 9,200 | 45 | 68 | 76 | 30 | 0.34 |
| FGK50 | 460 | 3,400 | 9,650 | 50 | 72 | 80 | 30 | 0.36 |
Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) specializes in manufacturing various cam clutches, one-way bearings, backstop clutches, and overrunning clutches with advanced technology.
We adhere to "Best Quality, Best Price, Fast Delivery, Best Service" to ensure customer satisfaction.
Samples are available for quality inspection and highly encouraged.
